Prolink 10KVA/8000W UPS Online (PRO910WS)
Rp58.156.230
PROLiNK Professional II Series (1P/1P) is a single-phase UPS system using microprocessor controlled true online double conversion technology and it can be used to provide protection for critical loads especially on IT applications.
Deskripsi
GENERAL
| UPS Type | Tower |
| Phase | Single phase with ground |
| Rating (VA) | 10000 |
| Nominal Power (W) | 8000 |
| Standard ModelDimension (mm) | 442 x 190 x 688 (D x W x H) |
| Weight (kg) | 66 |
| Long-run ModelDimestions (mm) | 442 x 190 x 318 (D x W x H) |
| Weight (kg) | 16 |
INPUT
| Connection Type | Terminal |
| Nominal Voltage | 208/220/230/240VAC |
| Voltage Range | 110-300 VAC (Load at 50%)176-300 VAC (Load at 100%) |
| Frequency Range | 46~54 Hz or 56~64 Hz |
| Power Factor | >= 0.99 |
OUTPUT
| Connection Type | Terminal |
| Output Voltage | 208/220/230/240VAC |
| Voltage Regulation | ±1% |
| Frequency Range (Synchronized Range) | 46~54 Hz or 56~64 Hz |
| Frequency Range (Batt. Mode) | 50Hz or 60Hz +/-0.1Hz |
| Current Crest Ratio | 3:1 |
| Harmonic Distortion | ≤3% THD (Linear load)≤5% THD (Non-linear load) |
ALARM & INDICATORS
| Battery Mode | Sounding every 4 seconds |
| Low Battery | Sounding every second |
| Overload | Sounding twice every second |
| Fault | Continuously sounding |
| LCD | Load level, Battery Level, AC mode, Battery mode, Bypass mode and Fault |
CONNECTIVITY, CONTROL & MONITORING
| Front panel | Status LED, Function keys, LCD display |
| Communication | Smart RS232*USB Port
Emergency Power Off (EPO) |
BATTERY
| Standard ModelType | 12V / 9Ah |
| Numbers | 16 |
| Typical Recharge Time | 9 hours recover to 90% capacity |
| Long-run ModelType | Depending on the capacity of external batteries |
| Number | 16 ~ 20 (Adjustable) |
| Charging Current (max) | 1A/2A/4A/6A (Adjustable, 6A is only available for 16pcs batteries) |
